SC101D Simplex Controller
Back to top |
Standard Features:
- Manual-Off-Auto Selector Switch
- Running and Failure Pilot Lights
- Seal Failure Pilot Light
- Level Input Pilot Lights
- High / Low Level Alarm Pilot Light
- Common Alarm Light with Dim Glow
- Common Alarm Dry Contact Output
- 24 VDC Level and Moisture Sensing Circuits with Intrinsic
Safety
- Adjustable Motor Failure Delay
- Adjustable Power On Delay Timer
- Adjustable Pump Start Delay
- Adjustable Seal Failure Delay
- Adjustable Short Cycle Delay
- Integrated Alarm Telemetry
- Lamp Test Feature
|
|
The model SC101D board is a 115 VAC powered solid-state instrument
that controls one fixed speed motor. The board is panel mounted
with integral terminals for field contacts. Front panel indicators
are provided for seal failure, motor failure, motor running and
high level. The seal failure and high level inputs can be used
as auxiliary inputs in the event the default functions are not
needed. Variable rate delays are provided for motor failure, seal
failure, power-on, motor start and short cycle. A Manual/Off/Auto
switch allows either fully automatic or manual operation. Alarm
indicators and outputs are provided for motor failure, seal failure
and high level.
All inputs are operated on +24Vdc. The Stop, Call-For, High Level
and Motor Running inputs are optically isolated from the rest
of the circuitry. CSI's Master Controller (MC101) board can be
tied into this unit for remote operation over a multiplexer system.
An optional Repeat Cycle Timer (SCRT) board and Seven Day Programmable
Timer (SC7DP) version of the board add to its functionality. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
SC7DP Simplex Controller
Back to top |
Standard Features:
- Integrated Quartz 7-Day Timer
- Manual-Off-Auto Selector Switch
- Running and Failure Pilot Lights
- Seal Failure Pilot Light
- Level Input Pilot Lights
- High / Low Level Alarm Pilot Light
- Common Alarm Light with Dim Glow
- Common Alarm Dry Contact Output
- 24 VDC Level and Moisture Sensing Circuits with Intrinsic
Safety
- Adjustable Motor Failure Delay
- Adjustable Power On Delay Timer
- Adjustable Pump Start Delay
- Adjustable Seal Failure Delay
- Adjustable Short Cycle Delay
- Integrated Alarm Telemetry
- Lamp Test Feature
|
|
The model SC7DP board is a 115 VAC powered solid-state instrument
that controls one motor. The board is panel mounted with integral
terminals for field contacts. Front panel indicators are provided
for seal failure, motor failure, motor running and high level. A
nameplate mounted solid-state quartz LCD timer provides automatic
motor control using field adjustable on and off times. The timer
has a rechargeable ni-cad battery for program retention during a
power failure. The seal failure and high level inputs can be used
as auxiliary inputs in the event the default functions are not needed.
Variable rate delays are provided for motor failure, seal failure,
power-on, motor start and short cycle. A Manual/Off/Auto switch
allows either fully automatic or manual operation. Alarm indicators
and outputs include motor failure, seal failure and high level.
All inputs operate on +24Vdc. The Stop, Call-For, High Level and
Motor Running inputs are optically isolated. CSI's Master Controller
(MC101) board can be tied into this unit for remote operation over
a multiplexer system. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
SCRT Simplex Repeat Cycle Timer
Back to top |
Standard Features:
- Automatic Motor Control
- Repeat Cycle Mode
- Maximum Run Time Mode
- Individually Set On/Off Times
- On and Off Times Independently Set in Either Seconds or Minutes
- Seconds Range: 1 to 1023
- Minutes Range: 1 to 1023
- Dry-Contact Relay Output
- Powered by SC101D Board
- Plugs onto Rear of SC101D Board
|
|
The SCRT repeat cycle timer board is an option board for SC101D
simplex controller. It enables automatic on/off control of a motor.
On and Off times are set independently and can be set in either
seconds or minutes. The board plugs onto the back of the SC101D
board, thus no more space is required for mounting and no external
power is required. The output is a relay dry contact with normally
open and closed contacts provided.
There are two modes of operation: a repeat cycle mode and a maximum
run time alarm mode. In repeat cycle mode, on and off times are
set by individual DIP switches. Time ranges are from 1 to 1023
seconds or minutes. The output is wired into the SC101D board
motor call-for inputs to control the motor. In maximum run time
alarm mode, the output serves as an alarm in the event the motor
runs longer than the time set by the SCRT board's ON time. There
are terminals for an external alarm reset switch for the maximum
run time mode. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
DC101D Duplex Controller
Back to top |
Standard Features:
- Manual-Off-Auto Selector Switch
- Motor Lead/Lag Selector Switch
- Running and Failure Pilot Lights
- Seal Failure Pilot Light
- Pilot Lights for each Level Input
- High / Low Level Alarm Pilot Light
- Common Alarm Light with Dim Glow
- Common Alarm Dry Contact Output
- Automatic Motor Alternation
- 24 VDC Level and Moisture Sensing Circuits with Intrinsic
Safety
- Lag Motor Start if Lead Fails
- Adjustable Motor Failure Delay
- Adjustable Power On Delay Timer
- Lamp Test Feature
|
|
The model DC101D board is a 115 VAC
powered solid-state instrument that controls two motors. The board
is panel mounted with a backplate mounted terminal board for field
contacts. Automatic alternation is provided along with variable
rate delays for motor failure and power-on. Manual/Off/Auto switches
allow either fully automatic or manual operation. Alarm indicators
and outputs are provided for motor failure, seal failure, high
level and improper sequence.
All inputs are operated on +24Vdc. The Stop, Lead Call-For, Lag
Call-For, High Level and Motor Running inputs are optically isolated
from the rest of the circuitry. Optional Float Test (FT101A),
Alarm Telemetry (DCAT) and Master Controller (MC101) boards make
this a very versatile system. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
DC201 Duplex Controller
Back to top |
Standard Features:
- Manual-Off-Auto Selector Switch
- Motor Lead/Lag Selector Switch
- Pilot Lights for Running, Failure, Seal Failure, High/Low
Level and Auxiliary Alarm
- Pilot Lights for each Level Input
- Common Alarm Light with Dim Glow
- Common Alarm Dry Contact Output
- Automatic Motor Alternation
- 15 VDC Optically Isolated Inputs with Max Current of 15 made
for Intrinsic Safety
- Lag Motor Start if Lead Fails
- Adjustable Motor Failure Delay
- Adjustable Seal Failure Delay
- Pump Lock-Out on Seal Failure Option
- Telemetry Outputs are Optically Isolated, Open-Collector Transistor
Types
- Lamp Test Input
- Remote Telemetry Unit (RTU) Capable with Industry Standard
Modbus or Bricknet Protocols
- Four Analog Inputs (4-20mA) - One for Level Transducer, Two
for Motor Currents and One for Motor Voltage or Other Requirements
- Two Serial Ports: One RS232 and One RS485
- RTU Addresses Supported: 000-999
- User Selectable Baud Rates of 4800 or 9600
- LSA2000 (Lift-Station Analyzer) Operation
- 120 VAC or 12 - 15VDC Power Supply
- Optional Float Test / Improper Sequence Alarm Board
- Optional Operator Interface Display
|
|
The model DC201 board is a 115 VAC
powered solid-state controller combining duplex controls with
a built-in Remote Telemetry Unit and Lift-Station Analyzer (LSA2000).
The board is panel mounted with a backplate mounted terminal board
for field contacts. Automatic alternation is provided along with
variable rate delays for motor failure and seal failure. Manual/Off/Auto
switches allow either fully automatic or manual operation. Alarm
indicators and outputs are provided for motor failure, seal failure,
high level, auxiliary alarm and improper sequence.
All inputs are optically isolated and operate on +15Vdc. Optional
Float Test (FT201A), Alarm Telemetry (DCAT) and Master Controller
(MC101) boards make this a very versatile system. The board is
the same size as the DC101, making it very easy to replace older
controllers with the DC201 for use in SCADA systems without having
to find additional space to wire in an external RTU. Remote Telemetry
features include industry standard communications protocols, operator
interface options, user-selectable baud rates, interfacing to
telephone or radio modems and System Control and Data Acquisition
(SCADA) systems. Four analog inputs are standard for RTU SCADA
transmission; one for tank level, two for motor currents and one
for motor voltage or other use. This multi-functional unit also
includes CSI's Lift-Station Analyzer circuitry which tracks vital
duplex lift-station statistics including influent flow rate and
totalized flow, tank level, pump runtimes, pump capacities and
back-pressure loss among others. Optional LCD operator interfaces
or laptop computers can be used to view lift-station statistics
locally. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
DCRT Duplex Repeat Cycle Timer
Back to top |
Standard Features:
- Automatic Motor Control
- Individually Set On/Off Times
- On and Off Times Independently Set in Either Seconds or Minutes
- Seconds Range: 1 to 1023
- Minutes Range: 1 to 1023
- Dry-Contact Relay Output
- Powered by DC101D Board
- Plugs onto Rear of DC101D Board
|
|
The DCRT repeat cycle timer board
is an option board for DC101D simplex controller. It enables automatic
on/off control of a motor. On and Off times are set independently
and can be set in either seconds or minutes. The board plugs onto
the back of the DC101D board, thus no more space is required for
mounting and no external power is required. The output is a relay
dry contact with normally open and closed contacts provided. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
DCATc Duplex Alarm Telemetry Board
Back to top |
Standard Features:
- 120 VAC Operation
- Quick-Change Plug In Connectors
- Individual Dry-Contact Outputs Rated at 5 Amps for Each Alarm
- LED Status Light for Each Output
- Solder Masked and Coated Board to Inhibit Corrosion
- Power Supply MOV Surge Protected
- GMA 1/2 Amp Fuse Protection
- Backplate Mounted
|
|
The model DCAT Duplex Alarm Telemetry
option board is a 115 VAC powered instrument that is used in conjunction
with CSI's Duplex Controller (models DC101A and later), to provide
external dry-contact relay outputs for alarm conditions. Motor
failure, seal failure, high level, improper sequence and auxiliary
outputs are provided. The board is backplate mounted and connects
to the DC101 board with a 9-conductor wiring harness. The DCAT
is protected from AC power surges by a 1/2 amp fuse and a 130
volt Metal Oxide Varistor (MOV). This option board gives extra
flexibility to CSI's Duplex Control System. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
FT101A Duplex Float Test Board
Back to top |
Standard Features:
- Powered by the Duplex Controller
- Test Pushbuttons for All-Stop, Lead Start, Lag Start and High
Level
- LED Status Indication of Control Levels
- Improper Sequence Indication
- Improper Sequence Reset Pushbutton
- Compatible with CSI's DC101A and later Duplex Controllers
- Panel Mounted
|
|
The model FT101A Float Test board is a panel mounted auxiliary board
that interfaces with Control System's Duplex Controller (DC101A
and later) to provide LED level indication and testing of the Duplex
Controller's level inputs. Test pushbuttons are provided for All-Stop,
Lead Start, Lag Start and High Level. These pushbuttons are wired
in parallel the actual field inputs. The board also provides visual
indication of an Improper Sequence condition and an Improper Sequence
Reset pushbutton. The board mounts next to the Duplex controller
and using complementary styling and controls, enhances the functions
of the Duplex Motor Control system. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
QC101B Duplex Controller
Back to top |
Standard Features:
- Manual-Off-Auto Selector Switch
- Front Panel Level Input Pilot Lights
- Motor Running and Failure Lights
- Seal Failure Pilot Lights
- Improper Sequence Pilot Light
- High / Low Level Alarm Pilot Light
- Common Alarm Light with Dim Glow
- Common Alarm Dry Contact Output
- Automatic Motor Alternation
- Motors Can Be Removed from the Alternation Sequence
- Separate Start and Stop Levels for Each Motor
- 24 VDC Level and Moisture Sensing Circuits with Intrinsic
Safety
- Lag Motor Start if Lead Fails
- Master Controller Inputs
- Maximum Run Timer
- Adjustable Motor Failure Delay
- Adjustable Power On Delay Timer
- Tri-Plex or Quadraplex Operation
- Lamp Test Feature
|
|
The model QC101B board is a 115 VAC powered solid-state instrument
that controls three or four motors. The board is panel mounted with
a backplate mounted terminal board for field contacts. Automatic
alternation is provided along with variable rate delays for motor
failure and power-on. Manual/Off/Auto switches allow either fully
automatic or manual operation. Each motor has its own separate start
and stop level input. A maximum run timer is also built into the
board. Alarm indicators and outputs are provided for motor failure,
seal failure, high level, auxiliary and improper sequence. All inputs
are operated on +24Vdc. The level, motor running and master controller
inputs are optically isolated. Optional Alarm Telemetry (QCAT) and
Master Controller (MC101) boards are available for increased functionality. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
QCAT Quadraplex Alarm Telemetry
Back to top |
Standard Features:
- 12 VDC Powered by QC101 Board
- Quick-Change Plug In Connectors
- Individual Dry-Contact Relay Outputs for Each Alarm
- Relay Contacts Rated for 5 Amps at 120 VAC
- Solder Masked and Coated Board to Inhibit Corrosion
- Backplate Mounted
- Quick Connect Terminal for Connection to the QC101 board
- Output Terminals Labeled for Easy Field Identification
|
|
The model QCAT Quadraplex Alarm Telemetry
option board is a 12 VDC powered instrument that is used in conjunction
with CSI's model QC101 board to provide external dry-contact relay
outputs for alarm conditions. Power is supplied by the QC101 board.
Motor failure, seal failure, high level, improper sequence and
auxiliary outputs are provide. The board is backplate mounted.
The board connects to the QC101 board with a 14-conductor wiring
harness. This option board gives extra flexibility to CSI's Quadraplex
Control System. |
|
To request additional information on any of these products, click
here.
Please be sure to mention which model(s) you are interested in.
|
